Option Explicit
Option Base 0
'
Public Sub オバケかぼちゃ描画マクロ()
Const PUMPLEFT = 100 '描画開始位置X
Const PUMPTOPP = 100 ' Y
Const PUMPVSPC = 40 '横-間隔
Const PUMPHSPC = 40 '縦-間隔
'
Const PUMPCOLS = 5 '横/描画数
Const PUMPROWS = 4 '縦/描画数
Const PUMPEYSZ = 6 '目のサイズ
Const PUMPEYVP = 5 '目の位置(外形中心より)
Const PUMPEYHP = -2.5
'
Const PUMPNSWD = 4 '鼻のサイズ
Const PUMPNSHT = 5
Const PUMPNSVP = 0 '鼻の位置(外形中心より)
Const PUMPNSHP = 0
'
Const PUMPMTVP = 0 '口の位置(外形中心より)
Const PUMPMTHP = 12
'
Const PUMPHTVP = 0 'へたの位置(外形中心より)
Const PUMPHTHP = -17
'
Const PUMPBZMG = 0.8 'ベジェ曲線倍率
' '↓ポリライン〃
Const PUMPP1MG = (PUMPBZMG * 2)
Const PUMPP2MG = (PUMPBZMG * 2.5)
Const PUNPLNWT = 1
'---------------------------------------------------------------------------
Dim Ip As Integer, Jp As Integer
Dim Kp As Integer
Dim intDxp As Integer, intDyp As Integer
Dim lngCol(2) As Long
Dim varBez As Variant, varPL1 As Variant
Dim varPL2 As Variant
Dim sngBBs(15, 1) As Single, sngBDt(15, 1) As Single
Dim sngP1B(17, 1) As Single, sngP1D(17, 1) As Single
Dim sngP2B(8, 1) As Single, sngP2D(8, 1) As Single
'
'*かぼちゃ外形ベジェデータ
varBez = Array(0#, 18.7, 16.5, 18.2, 20.2, 13.7, 20.9, 0.3, _
20.3, -12.3, 12#, -13.4, 7.7, -8.4, 6.2, -13.8, -9.1, -14.6, _
-10.2, -8.9, -16.8, -14.5, -21.2, -11.1, -21.1, 0.2, -20.8, _
13.7, -16.5, 16.7, -0.1, 18.7)
'*口のポリラインデータ
varPL1 = Array(-5#, 3#, -3#, 3#, -3#, 1#, -1#, 1#, -1#, 3#, _
1#, 3#, 1#, 1#, 3#, 1#, 3#, 3#, 5#, 3#, 5#, -3#, 4#, -3#, 2#, _
-3#, 2#, -1#, 0#, -1#, 0#, -3#, -5#, -3#, -5#, 3#)
'*へたのポリラインデータ
varPL2 = Array(-0.6, -0.4, 0.6, -0.8, 0.3, 2#, 1.4, 2.2, 1.9, _
2.8, -0.9, 3.4, -1.7, 2.6, -0.5, 2#, -0.6, -0.4)
'*データ設定
For Kp = LBound(sngBBs, 1) To UBound(sngBBs, 1)
sngBBs(Kp, 0) = CSng(varBez(Kp * 2 + 0)) * PUMPBZMG
sngBBs(Kp, 1) = CSng(varBez(Kp * 2 + 1)) * PUMPBZMG
Next Kp
For Kp = LBound(sngP1B, 1) To UBound(sngP1B, 1)
sngP1B(Kp, 0) = CSng(varPL1(Kp * 2 + 0)) * PUMPP1MG
sngP1B(Kp, 1) = CSng(varPL1(Kp * 2 + 1)) * PUMPP1MG * -0.5
Next Kp
For Kp = LBound(sngP2B, 1) To UBound(sngP2B, 1)
sngP2B(Kp, 0) = CSng(varPL2(Kp * 2 + 0)) * PUMPP2MG
sngP2B(Kp, 1) = CSng(varPL2(Kp * 2 + 1)) * PUMPP2MG
Next Kp
'
lngCol(0) = vbBlack '←輪郭、穴の色
lngCol(1) = RGB(255, 165, 0) '←かぼちゃの色
lngCol(2) = RGB(0, 100, 0) '←へたの色
'
For Jp = 0 To PUMPROWS - 1
intDyp = PUMPTOPP + PUMPHSPC * Jp
For Ip = 0 To PUMPCOLS - 1
intDxp = PUMPLEFT + PUMPVSPC * Ip
'*外形描画位置設定
For Kp = LBound(sngBBs, 1) To UBound(sngBBs, 1)
sngBDt(Kp, 0) = sngBBs(Kp, 0) + intDxp
sngBDt(Kp, 1) = sngBBs(Kp, 1) + intDyp
Next Kp
'*外形(ベジェ曲線)描画
With ActiveDocument.Shapes.AddCurve(sngBDt)
.Fill.Visible = msoTrue
.Fill.ForeColor.RGB = lngCol(1)
.Line.Visible = msoTrue
.Line.ForeColor.RGB = lngCol(0)
.Line.Weight = PUNPLNWT
End With
'*目(二等辺三角形)描画
For Kp = 0 To 1 '左/0 右/1
With ActiveDocument.Shapes.AddShape( _
msoShapeIsoscelesTriangle, _
intDxp + IIf(Kp = 0, _
PUMPEYVP * -1 - PUMPEYSZ, _
PUMPEYVP) * PUMPBZMG, _
intDyp + PUMPEYHP * PUMPBZMG, _
PUMPEYSZ * PUMPBZMG, _
PUMPEYSZ * PUMPBZMG)
.Fill.Visible = msoTrue
.Fill.ForeColor.RGB = lngCol(0)
.Line.Visible = msoFalse
.Flip msoFlipVertical '上下反転
End With
Next Kp
'*鼻(二等辺三角形)描画
With ActiveDocument.Shapes.AddShape( _
msoShapeIsoscelesTriangle, _
intDxp + (PUMPNSVP - PUMPNSWD / 2) _
* PUMPBZMG, _
intDyp + PUMPNSHP * PUMPBZMG, _
PUMPNSWD * PUMPBZMG, _
PUMPNSHT * PUMPBZMG)
.Fill.Visible = msoTrue
.Fill.ForeColor.RGB = lngCol(0)
.Line.Visible = msoFalse
End With
'*口描画位置設定
For Kp = LBound(sngP1B, 1) To UBound(sngP1B, 1)
sngP1D(Kp, 0) = sngP1B(Kp, 0) + intDxp _
+ PUMPMTVP * PUMPBZMG
sngP1D(Kp, 1) = sngP1B(Kp, 1) + intDyp _
+ PUMPMTHP * PUMPBZMG
Next Kp
'*口(ポリライン)描画
With ActiveDocument.Shapes.AddPolyline(sngP1D)
.Fill.Visible = msoTrue
.Fill.ForeColor = lngCol(0)
.Line.Visible = msoFalse
End With
'*へた描画位置設定
For Kp = LBound(sngP2B, 1) To UBound(sngP2B, 1)
sngP2D(Kp, 0) = sngP2B(Kp, 0) + intDxp _
+ PUMPHTVP * PUMPBZMG
sngP2D(Kp, 1) = sngP2B(Kp, 1) + intDyp _
+ PUMPHTHP * PUMPBZMG
Next Kp
With ActiveDocument.Shapes.AddPolyline(sngP2D)
.Fill.Visible = msoTrue
.Fill.ForeColor.RGB = lngCol(2)
.Line.Visible = msoTrue
.Line.ForeColor.RGB = lngCol(0)
.Line.Weight = PUNPLNWT
End With
Next Ip
Next Jp
End Sub
